4inch HDMI Capacitive Touch IPS LCD Display (C), 720×720, Optical Bonding Screen

Kategori

LCD

Marka

Waveshare

Stok Kodu

4inch HDMI LCD (C)

4inch HDMI Capacitive Touch IPS LCD Display (C), 720×720, Optical Bonding Screen

4inch HDMI Capacitive Touch IPS LCD Display (C), 720×720, Optical Bonding Screen

Teklif İsteyiniz

Yorum
Yaz

ÜRÜN BİLGİSİ

4″ HDMI Touch Display

- - - - Size4″

        Resolution720×720

        Display InterfaceHDMI

        Display PanelIPS

        Viewing Angle170°

        Touch TypeCapacitive

        Touch Points5-Points

        Touch Port 1USB-C

        Touch Port 2I2C

        Touch PanelToughened Glass

        Touch Panel TechOptical Bonding

        OSD MenuBrightness/Contrast

        Audio Output 13.5mm Jack

        Audio Output 24PIN Header

Device & System Support

Raspberry Pi

Supports Raspberry Pi OS / Ubuntu / Kali / WIN10 IoT / Retropie
Driver free for USB-C touch
Config file is required for I2C touch

Supports all versions of Raspberry Pi

Jetson Nano

Supports Ubuntu

Supports Windows 11 / 10 / 8.1 / 8 / 7

for Jetson Nano and PC, only USB-C touch is available

Connection Examples

Working With Raspberry Pi 4

Working With Raspberry Pi 3B+

Working With Jetson Nano AI Computer

Working With Mini PC

Display

IPS Panel

Touch Control

1) up to 5-points touch, depending on the operating system. 2) up to 6H hardness toughened glass panel. 3) Optical Bonding screen, better display experience, dust-proof.

Design Features

Appearance And Dimensions

Ekran Boyutu

4 inch
