MRTK-BLQ-C, 0-2500MHz Surge Protectors N Male To N Female
Yıldırım ve Gerilim Koruyucu. Tüm cihaz ve antenlerle uyumludur.
Surge arresters are the primary protection against atmospheric and switching over voltages.
Bi-Directional Protection (N-Male / N-Female Connectors) - Bulkhead / Panel / Outdoor Mountable
- High Quality Construction
Very Low RF Insertion Loss (Signal Attenuation) - 50 Ohm Impedance - DC Pass-Through
Gas Discharge Tube with Multi-Strike Capability Shunts Damaging Surges, Transients, and Lightning
Strikes to Ground,Connect to Antenna Coax Feedline and Earth Ground F mate to F female 50 Ohm
compatible with 50 Ohm F connector cell phone signal boosters, 2.4GHz Wireless LAN WiFi antennas,
GPS receivers, microwave communication system, broadcast television.
Protect your signal booster amplifier system from dangerous lightning strikes or electrical surges by
installing the lightning arrestor between the amplifier and the outdoor antenna.
Standard 90 V DC breakdown voltage gas discharge tube (GDT) element which can be easily replaced
to provide multistrike capacity.
Frequency Range up to 3 GHz covers 2G 3G 4G LTE cell phone signal boosters, 2.4GHz Wireless
LAN WiFi,WiMAX, FM, AM, VHF and UHF broadcast network surge suppression.
Designed and manufactured the lightning surge protector body material with high quality nickel plated
brass to provide superior performance and longevity.
| Electrical | |
| Frequency Range | 0-2500MHz |
| VSWR | ≤1.2 |
| Maximum Input Power | 200W |
| Discharge inception voltage | DC230 |
| Impedance | 50Ω |
| Insert Loss | ≤0.2 |
| Input Connector | N-K/ N-J |
| Dimensions | 74×42×20mm |
| Weight | 130g |
