MV31 , 5G Modül , Ultra High Speed IoT Modem Card (5G)
The award-winning MV32-W IoT is the latest generation of 3GPP release 16 compliant 5G modem cards, a new addition to the MV series after the success of the MV31. The MV32 further improves on class-leading thermal efficiency and enables unrivalled throughput performance in an extremely compact card form factor with an integrated eSIM inside.
Access to the entire 5G spectrum:
- 5G Sub-6, eMBB with reliable, low latency communication capabilities
- Global 5G coverage on one single SKU
- LTE Cat.20 fallback
Product Description
The compact solution is the smallest of its kind supporting the entire 5G spectrum with FR1 sub-6GHz and FR2 mmWave bands. It enables blistering fast data speeds of multiple gigabit per second transmission capability in both downlink and uplink plus fallback to 4G LTE and 3G networks. It also provides excellent global coverage in both urban areas and regions where 5G is still emerging.
Most compact plug and play M.2 data card:
– Compact standard 30×42 M.2 with PCIe3.0 and USB 3.1 support
– Support of Windows 10 and 11, Linux and Android 12
Flexible Network usage:
– Dual SIM Single Activate (DSSA)
– Key MNO approvals
– Flexible SIM support: embedded SIM or dual external SIM support
True Industrial IoT:
– Temp: -40 to +85 C°
– Advanced temperature management
– Special heat dissipation design
Proven cellular configuration:
– Unique RF Core encapsulates complexity and increases reliability
– Core cellular configuration tested and approved
Form Factor Family
Industry-standard edge-connected M.2 mini cards formerly known as the Next Generation Form Factor (NGFF). Telit M.2 cards comply to the key B standard and can be 42 or 50 mm long, single- and double-sided form factors depending on model.
General Features:
- 5G SA and NSA (3GPP Release 15)
FR1 FDD-LTE Bands: n1, n2, n3, n5, n7, n8, n12, n20, n28, n66, n71
FR1 TD-LTE Bands: n38, n41, n77, n78, n79
FR2 mmWave: n257, n258, n260, n261 - LTE Advanced-Pro (3GPP Release 15)
- FDD-LTE Bands: 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 32, 66, 71
- TD-LTE Bands: 34, 38, 39, 40, 41, 42, 46 (LAA), 48 (CBRS)
- UMTS/HSPA+ (3GPP Release 8):
FDD Bands: 1, 2, 4, 5, 6, 8, 9, 19 - Optional mmWave support
- Worldwide coverage in single SKU
- 5G Standalone (SA) and Non-Standalone (NSA) Support
- Integrated Dual Frequency GNSS: Simultaneous L1 and L5 supporting GPS, GLONASS, Galileo and Beidou
- Supply voltage range 3.14V – 4.8V
- Data only
Specifications:
- 5G Sub6 Ghz: Max throughput DL/UL ~4 Gbps/ ~0.7 Gbps*
- 5G mmWave: Max throughput DL/UL ~6 Gbps/~3 Gbps*
- LTE Cat. 20: Max throughput DL/UL 2 Gbps / 150 Mbps*
- HSPA+ Rel8: Max throughput DL/UL 42 Mbps / 11 Mbps*
Certifications:
- CE/RED, RoHS/REACH, FCC, ISED, GCF, PTCRB, RCM, JATE/TELEC, NCC
- MNOs supported: AT&T incl. Firstnet, Verizon, TMO US, NTT Docomo, KDDI, Softbank
Dimensions:
- 30 x 42 x 2.5 mm – Smallest 5G M.2 data card
Temperature Range:
- Extended operation -40° C to +85° C
Interfaces:
- PCIe 3.0 / USB 3.1 Gen.2 SuperSpeed
- 4x MHF4 on-board connectors for Sub6 GHz frequencies (shared with GNSS)
- 3x 2-in-1 IF connectors for mmWave antennas
Special Features:
- eSIM onboard + external SIM or optional ext. Dual SIM
- Dynamic Power Reduction (DPR) with control over software
- Unique hardware design for performance and thermal efficiency
Drivers Support:
- Windows® 10
- Linux®
- Android
