Kategori
433MHz LoRa Modül , 868MHz LoRa Modül
Marka
EBYTE
Stok Kodu
E32-T
E32-T Serisi , LoRa RF Modül

E32-T Serisi , LoRa RF Modül

Fiyat
5,00 USD + KDV
174,92 TL + KDV
Seçenekler
Modül Serisi
SEPETE EKLE HEMEN AL
ÜRÜN BİLGİSİ
Model Interface IC Frequency Hz Power dBm Distance km Air data rate Package Size (mm) Feature Manual
E32-400T20S3 UART SX1278 433M 470M 20 3,0 0.3k~19.2k SMD 16 * 26 LoRa spread spectrum ✔
E32-433T20DC UART SX1278 433M 20 3.0 0.3k~19.2k DIP 21*36 LoRa spread spectrum ✔
E32-433T20DT UART SX1278 433M 20 3.0 0.3k~19.2k DIP 21*36 LoRa spread spectrum ✔
E32-433T20S UART SX1278 433M 20 5,0 2.4k～19.2k SMD 16 * 26 LoRa Spread Spactrum Technology ✔
E32-433T20S1 UART SX1278 433M 20 3.0 0.3k~19.2k SMD 17*25.5 LoRa spread spectrum ✔
E32-433T20S2T UART SX1278 433M 20 3.0 0.3k~19.2k SMD 17*30 LoRa spread spectrum ✔
E32-433T27D UART SX1278 433M 27 5.0 0.3k~19.2k DIP 24*43 LoRa spread spectrum ✔
E32-433T30D UART SX1278 433M 30 8.0 0.3k~19.2k DIP 24*43 LoRa spread spectrum ✔
E32-433T30S UART SX1278 433M 30 8.0 0.3k~19.2k SMD 25*40.5 LoRa spread spectrum ✔
E32-868T20D UART SX1276 868M 20 3.0 0.3k~19.2k DIP 21*36 LoRa spread spectrum ✔
E32-868T20S UART SX1276 868M 20 3,0 0.3k~19.2k SMD 16 * 26 LoRa spread spectrum ✔
E32-868T30D UART SX1276 868M 30 8.0 0.3k~19.2k DIP 24*43 LoRa spread spectrum ✔
E32-868T30S UART SX1276 868M 30 8.0 0.3k~19.2k DIP 25*40.3 LoRa spread spectrum Continuous transmiss ✔
E32-900T20S UART SX1276 868M 915M 20 5,5 0.3k~19.2k SMD 16*26 LoRa spread spectrum ✔
E32-900T30D UART SX1276 868M 915M 30 8,0 0.3k~19.2k DIP 24*43 LoRa spread spectrum ✔
